前言

前期加班加点赶项目, 趁着刚上线空两天,赶紧看下EventBus做个"思维复健"

使用

EventBus的使用非常简单, 如果使用默认的EventBus, 我们一般只会使用到以下三个API

1. 绑定

EventBus.getDefault().regisiter(this);复制代码

2. 发送信息

EventBus.getDefault().post(new Event());复制代码

3. 解绑

EventBus.getDefault().unregisiter(this);复制代码

EventBus.getDefault()

EventBus内部维护了一个单例, 通过getDefault我们可以获取默认单例来进行绑定和发送动作, 但是当我们需要进行一些关于log, 是否未有订阅者情况的响应处理时, 我们可以通过EventBusBuilder通过构建者模式来进行配置处理,本篇解析仅分析默认情况下的流程代码

绑定

老规矩, 我们先上代码

public void register(Object subscriber) {        Class
     subscriberClass = subscriber.getClass();        // 获取对应subscriber类的订阅方法        List

      subscriberMethods = subscriberMethodFinder.findSubscriberMethods(subscriberClass);        synchronized (this) {            // 遍历执行订阅            for (SubscriberMethod subscriberMethod : subscriberMethods) {                subscribe(subscriber, subscriberMethod);            }        }    }复制代码


我们根据传递的订阅者来获取相关的订阅方法, 然后遍历执行订阅的动作. 我们首先看下如果查找订阅者的所有订阅方法

List

      findSubscriberMethods(Class
      subscriberClass) {        // 从缓存中查找订阅方法        List

       subscriberMethods = METHOD_CACHE.get(subscriberClass);        // 缓存中有, 直接返回        if (subscriberMethods != null) {            return subscriberMethods;        }        // 查找注册方法, 默认false        if (ignoreGeneratedIndex) {            // 使用反射查找            subscriberMethods = findUsingReflection(subscriberClass);        } else {            // 使用注解器生成的类查找            subscriberMethods = findUsingInfo(subscriberClass);        }        // 如果没有订阅方法, 则抛出异常        if (subscriberMethods.isEmpty()) {            throw new EventBusException("Subscriber " + subscriberClass                    + " and its super classes have no public methods with the @Subscribe annotation");        } else {            // 否则加入缓存中            METHOD_CACHE.put(subscriberClass, subscriberMethods);            return subscriberMethods;        }    }复制代码



我们知道EventBus3.0版本后通过@Subscribe注解来标注对应的订阅方法, 可以看到通过findUsingInfo方法查询订阅方法, 如果没有订阅方法, 会抛出异常, 而如果找到了, 则会加入缓存METHOD_CACHE进行内部维护, 这个方法可以优化部分性能, 减少反射带来的性能问题. 我们在往findUsingInfo里看, 会发现如果找不到相关订阅者信息的时候, 仍会通过反射来寻找.

private List

      findUsingInfo(Class
      subscriberClass) {        FindState findState = prepareFindState();        findState.initForSubscriber(subscriberClass);        while (findState.clazz != null) {            findState.subscriberInfo = getSubscriberInfo(findState);            if (findState.subscriberInfo != null) {                SubscriberMethod[] array = findState.subscriberInfo.getSubscriberMethods();                // 遍历订阅者方法                for (SubscriberMethod subscriberMethod : array) {                    if (findState.checkAdd(subscriberMethod.method, subscriberMethod.eventType)) {                        findState.subscriberMethods.add(subscriberMethod);                    }                }            } else {                // 没有订阅信息, 从反射来找                findUsingReflectionInSingleClass(findState);            }            findState.moveToSuperclass();        }        return getMethodsAndRelease(findState);    }复制代码


我们回头去看subscribe订阅动作的执行代码

/**     * 订阅动作     * @param subscriber         订阅者(类似订阅的Activity之类)     * @param subscriberMethod   订阅事件方法, 比如加了@Subscribe注解的方法     */    private void subscribe(Object subscriber, SubscriberMethod subscriberMethod) {        // 订阅事件的类, 比如平常传递的自己写的EventLogin等等..        Class
     eventType = subscriberMethod.eventType;        Subscription newSubscription = new Subscription(subscriber, subscriberMethod);        // 获取与eventType有关的订阅事件的队列        CopyOnWriteArrayList

      subscriptions = subscriptionsByEventType.get(eventType);        // 如果为空        if (subscriptions == null) {            // 初始队列            subscriptions = new CopyOnWriteArrayList<>();            subscriptionsByEventType.put(eventType, subscriptions);        } else {            // 如果管理的订阅队列存在新的订阅事件, 则抛出已注册事件的异常            if (subscriptions.contains(newSubscription)) {                throw new EventBusException("Subscriber " + subscriber.getClass() + " already registered to event "                        + eventType);            }        }        int size = subscriptions.size();        // 遍历订阅的事件        for (int i = 0; i <= size; i++) {            // 根据优先级, 插入订阅事件            if (i == size || subscriberMethod.priority > subscriptions.get(i).subscriberMethod.priority) {                subscriptions.add(i, newSubscription);                break;            }        }        // 以订阅者为key, value为订阅事件的类的队列        List

      > subscribedEvents = typesBySubscriber.get(subscriber);        if (subscribedEvents == null) {            subscribedEvents = new ArrayList<>();            typesBySubscriber.put(subscriber, subscribedEvents);        }        subscribedEvents.add(eventType);        // 是否粘性事件        if (subscriberMethod.sticky) {            // 是否分发订阅了响应事件类父类事件的方法, 默认为true            if (eventInheritance) {                // Existing sticky events of all subclasses of eventType have to be considered.                // Note: Iterating over all events may be inefficient with lots of sticky events,                // thus data structure should be changed to allow a more efficient lookup                // (e.g. an additional map storing sub classes of super classes: Class -> List

       ).                // stickyEvents 粘性事件集合, key为eventType的类, value是eventType对象                Set


         , Object>> entries = stickyEvents.entrySet();                for (Map.Entry

          , Object> entry : entries) { // 获取候选eventType Class
           candidateEventType = entry.getKey(); // native方法, 应该是判断当前注册eventType与候选缓存的eventType是否匹配 if (eventType.isAssignableFrom(candidateEventType)) { // 如果匹配, 校验并发送订阅 Object stickyEvent = entry.getValue(); checkPostStickyEventToSubscription(newSubscription, stickyEvent); } } } else { Object stickyEvent = stickyEvents.get(eventType); checkPostStickyEventToSubscription(newSubscription, stickyEvent); } } }复制代码







相关注释都在代码里, 这块的流程我们可以梳理成以下步骤:

1. 获取我们订阅时间传输的类EventType, 初始化内部维护的两个集合, 分别是subscriptionsByEventType和typesBySubscriber, 根据命名我们也可以理解, 一个是根据eventType区分的订阅者队列, 一个是根据subscriber(订阅者)区分的eventType队列, 分别向对应的集合内添加对应新的订阅者和订阅事件
2. 根据是否粘性事件判断是否需要调用checkPostStickyEventToSubscription直接发送信息给订阅者
3. checkPostStickyEventToSubscription内部判断事件是否被中断来判断是否会调用到postToSubscription, 就是发送信息给订阅者

发送信息

/**     * 事件发送     */    /** Posts the given event to the event bus. */    public void post(Object event) {        // currentPostingThreadState 为ThreadLocal对象        // 获取当前线程的发送状态        PostingThreadState postingState = currentPostingThreadState.get();        // 获取当前线程的事件发送队列        List

由于在业务场景中, 无法判断发送信息在什么线程下执行的, 所以内部维护的currentPostingThreadState是一个ThreadLocal对象, 它可以保证当前线程的数据不会被其他线程共享.在post中, 我们就能看到EventBus会根据当前线程, 将事件发送给当前线程的队列中, 然后遍历执行postSingleEvent进行单个事件的发送, 同时移除掉队列中已发送的事件

/**     * 发送单个事件     * @param event     * @param postingState     * @throws Error     */    private void postSingleEvent(Object event, PostingThreadState postingState) throws Error {        // event 是对应eventType的实例        Class
     eventClass = event.getClass();        // 默认没有找到订阅者        boolean subscriptionFound = false;        // 默认true, 判断是否触发eventType的父类或接口的订阅        if (eventInheritance) {            // 查找获取所有eventType的父类和接口            List

     > eventTypes = lookupAllEventTypes(eventClass);            int countTypes = eventTypes.size();            // 循环发送            for (int h = 0; h < countTypes; h++) {                Class
      clazz = eventTypes.get(h);                subscriptionFound |= postSingleEventForEventType(event, postingState, clazz);            }        } else {            subscriptionFound = postSingleEventForEventType(event, postingState, eventClass);        }        // 如果没有找到订阅者        if (!subscriptionFound) {            if (logNoSubscriberMessages) {                logger.log(Level.FINE, "No subscribers registered for event " + eventClass);            }            // 如果我们的builder配置了sendNoSubscriberEvent(默认为true)            if (sendNoSubscriberEvent && eventClass != NoSubscriberEvent.class &&                    eventClass != SubscriberExceptionEvent.class) {                // 会发送一个NoSubscriberEvent的事件, 如果需要判断无订阅者时候的触发情况, 可以接收这个事件做处理                post(new NoSubscriberEvent(this, event));            }        }    }复制代码


这里的流程我们可以分成两步:

1. 通过postSingleEventForEventType根据eventType查找对应的订阅者, 如果找到, 则发送事件
2. 如果没有找到订阅者, 根据构造器内我们通过sendNoSubscriberEvent的配置, 来判断是否需要发送一个无订阅者响应事件

private boolean postSingleEventForEventType(Object event, PostingThreadState postingState, Class
     eventClass) {        CopyOnWriteArrayList

      subscriptions;        synchronized (this) {            // 根据eventType获取订阅者            subscriptions = subscriptionsByEventType.get(eventClass);        }        if (subscriptions != null && !subscriptions.isEmpty()) {            for (Subscription subscription : subscriptions) {                postingState.event = event;                postingState.subscription = subscription;                boolean aborted = false;                try {                    // 发送给订阅者                    postToSubscription(subscription, event, postingState.isMainThread);                    aborted = postingState.canceled;                } finally {                    postingState.event = null;                    postingState.subscription = null;                    postingState.canceled = false;                }                if (aborted) {                    break;                }            }            return true;        }        return false;    }复制代码


postSingleEventForEventType方法就执行了上面的第一步动作, 如果找到了订阅者, 就会返回true; 否则, 返回false.最终我们通过调用postToSubscription将事件发送给订阅者. 咱们继续往下走.

/**     * 订阅发布     * @param subscription 新注册的订阅者     * @param event eventType     * @param isMainThread 是否主线程     */    private void postToSubscription(Subscription subscription, Object event, boolean isMainThread) {        // 订阅方法的指定线程        switch (subscription.subscriberMethod.threadMode) {            // 相同线程内            case POSTING:                invokeSubscriber(subscription, event);                break;            // 主线程内, 不阻塞            case MAIN:                if (isMainThread) {                    // 订阅者的调用                    invokeSubscriber(subscription, event);                } else {                    // 通过handler处理                    mainThreadPoster.enqueue(subscription, event);                }                break;            // 主线程, 阻塞            case MAIN_ORDERED:                if (mainThreadPoster != null) {                    mainThreadPoster.enqueue(subscription, event);                } else {                    // temporary: technically not correct as poster not decoupled from subscriber                    invokeSubscriber(subscription, event);                }                break;            // 后台线程,            case BACKGROUND:                if (isMainThread) {                    // 实现了Runnable                    backgroundPoster.enqueue(subscription, event);                } else {                    invokeSubscriber(subscription, event);                }                break;            // 异步线程            case ASYNC:                asyncPoster.enqueue(subscription, event);                break;            default:                throw new IllegalStateException("Unknown thread mode: " + subscription.subscriberMethod.threadMode);        }    }复制代码

默认的线程模式一般是POSTING会走发送信息时所在的线程, 这样避免了线程切换所存在的可能开销.我们首先看下invokeSubscriber方法, 它的作用就是做到了订阅者的调用

void invokeSubscriber(Subscription subscription, Object event) {        try {            // 订阅方法的调用            subscription.subscriberMethod.method.invoke(subscription.subscriber, event);        } catch (InvocationTargetException e) {            handleSubscriberException(subscription, event, e.getCause());        } catch (IllegalAccessException e) {            throw new IllegalStateException("Unexpected exception", e);        }    }复制代码

其实可以看出, 这里就是获取订阅方法, 通过反射将事件作为参数调用.

我们看下走UI线程的流程, 在判断当前线程非主线程的情况下, 我们会调用到mainThreadPoster.enqueue(subscription, event);, 首先, 我们回到EventBus的构造函数中, 找到mainThreadPoster的相关申明

mainThreadPoster = mainThreadSupport != null ? mainThreadSupport.createPoster(this) : null;复制代码

public interface MainThreadSupport {    boolean isMainThread();    Poster createPoster(EventBus eventBus);    class AndroidHandlerMainThreadSupport implements MainThreadSupport {        private final Looper looper;        public AndroidHandlerMainThreadSupport(Looper looper) {            this.looper = looper;        }        @Override        public boolean isMainThread() {            return looper == Looper.myLooper();        }        @Override        public Poster createPoster(EventBus eventBus) {            return new HandlerPoster(eventBus, looper, 10);        }    }}复制代码

可以看到他是个HandlerPoster对象, 然后再回来看HandlerPoster.enqueue对应的代码

public void enqueue(Subscription subscription, Object event) {        PendingPost pendingPost = PendingPost.obtainPendingPost(subscription, event);        synchronized (this) {            queue.enqueue(pendingPost);            if (!handlerActive) {                handlerActive = true;                if (!sendMessage(obtainMessage())) {                    throw new EventBusException("Could not send handler message");                }            }        }    }复制代码

这里首先维护了内部的PendingPost, 并且将对应的pendingPost加入执行队列中.HandlerPoster继承于Handler, 根据他前面传入的Looper可以判定保证信息的执行是在主线程中做处理的, 现在我们看下handleMessage的处理

@Override    public void handleMessage(Message msg) {        boolean rescheduled = false;        try {            long started = SystemClock.uptimeMillis();            while (true) {                PendingPost pendingPost = queue.poll();                if (pendingPost == null) {                    synchronized (this) {                        // Check again, this time in synchronized                        pendingPost = queue.poll();                        if (pendingPost == null) {                            handlerActive = false;                            return;                        }                    }                }                // 调用订阅者                eventBus.invokeSubscriber(pendingPost);                long timeInMethod = SystemClock.uptimeMillis() - started;                if (timeInMethod >= maxMillisInsideHandleMessage) {                    if (!sendMessage(obtainMessage())) {                        throw new EventBusException("Could not send handler message");                    }                    rescheduled = true;                    return;                }            }        } finally {            handlerActive = rescheduled;        }    }复制代码

这里做的处理, 主要就是调用了EventBus对象的invokeSubscriber方法, 最终走到了订阅者的方法的执行. 至于其他的几个线程模式, 查看对应的POST也可以大致知道他的原理, 这里就暂且不表了.

解绑

相对前面的, 其实解绑的逻辑就非常简单了, 我们先看代码

/**     * 解绑     */    /** Unregisters the given subscriber from all event classes. */    public synchronized void unregister(Object subscriber) {        // 根据订阅者获取对应的eventType        List

     > subscribedTypes = typesBySubscriber.get(subscriber);        // 如果不为空        if (subscribedTypes != null) {            // 遍历解绑            for (Class
      eventType : subscribedTypes) {                unsubscribeByEventType(subscriber, eventType);            }            // 移除相关的eventType            typesBySubscriber.remove(subscriber);        } else {            logger.log(Level.WARNING, "Subscriber to unregister was not registered before: " + subscriber.getClass());        }    }复制代码


我们在绑定相关的解析中, 已经知道其实内部管理订阅事件和订阅者是通过typesBySubscriber和subscriptionsByEventType来实现的, 而这里就是移除掉与对应订阅者相关的对象即可.
